Stationary Shelters
Cinderblock beehive dome building Jig
An early rendition of a 16 foot diameter Beehive shaped dome. Years ago I was interested in Geodesic domes until, being a drywall finisher, I had the misfortune to mud one of these beasts. Luckily the home owner, already finding the expenses way too high for this project, allowed us to use a rubber trowel…
Read More
Hexadome
This six sided dome was made using 8 sheets of 4mm thick recycled campaign signs and duct tape. Similar to my Octatipi in construction, the sides on this shelter flare out giving you more interior head space. The floor uses two 4×8 ft. campaign sign, bent up at the edges and housed inside the walls…
Read More
Bug screen tent canopy
I took a canopy made for beds and make an outdoor nook for my wife and I to sit in and enjoy the summer, bug free. For the stakes I cut 10 ft rebar lengths in two, then I cut an X in tennis balls and slipped them over the stake ends. I draped the…
Read More
Burningman box shelter
This was my first use of Coroplast, or better known as fluted plastic or plastic cardboard. This 2-1/2 sheet 4 ft square box used 2×2’s for corner framing. Button head screws fastened the panels to the frame. For transport the shelter was made modular. All I had to do was attach the corner frame to…
Read More
Recycled Campaign sign shelter
This 4 ft high by 8 ft long shelter was built almost exclusively from recycled election campaign signs including the lumber and hardware. Attached to the exterior green house is a pole that holds the gravity fed solar shower bag positioned toward the sun. Rain water is harvested for taking showers. To keep…
Read More
Burningman micro shelter
This 3 sheet 1″ thick Gorilla duct taped shelter hasn’t made it to Burningman, but was designed for playa use. Having a plywood top creates anchoring points for tie down lines, and makes it strong enough to sit on top, at least for me. If you’re heavier than 175 pounds I’d go with 1-1/2″ thick…
Read More
Burningman foam board shelter
The 1″ thick Pyramid from the year before proved a little time consuming to erect, so I came up with this quick deployment 9 sided shelter using 1-1/2″ thick foam board. It’s a bit smaller than the pyramid but we were still able to have a table for cooking and cozy seating for five…
Read More
Burningman pyramid shelter
This was my first try making foam board shelters. I have to credit Vina Gupta for developing the foam board Hexayurts. But I wanted something original, so I chose a 12′ square pyramid to hang out in and an octagonal teepee for the bedroom. old buddy GI Joe was instrumental in modeling my idea. The middle…
Read More
Homeless sleeping pod #2
On the first pod base I used three recycled pallets. Here I’m experimenting with 2×2’s for the base frame, later adding 1/2″ OSB for the floor. This proved too weak. On the final version I used four treated 2×4’s and 1/2″ OSB sheeting. This proved very robust. Although costing a bit more, going this route saved…
Read More
